Accuracy: Class C/ R160
Compatible with multiple communication modules
Optical Port, M-BUS, RS-485, Pulse output, LoRa RF, LoRaWAN, NB-IoT, 4G (CAT 1)
Single-jet, Dry-dial, Magnetic drive, Anti-magnetic Protection
Available for cold water (50°C) and hot water (90°C)
Sizes: DN15 to 25 mm (½” – 1”).
Body material: Brass
MAIN TECHNICAL DATA
DN15 DN20 DN25 Q4 (Qoverload) m³/h 3. 125 3. 125 5 5 7.875 7.875 Q3 (Qmax/permanent) m³/h 2.5 2.5 4 4 6.3 6.3 Q2 (Qtransitional) m³/h 0.05 0.025 0.08 0.04 0.126 0.063 Q1 (Qmin) m³/h 0.03125 0.015625 0.05 0.025 0.07875 0.039375 Start Flow Rate m³/h 0.01 0.005 0.014 0.007 0.02 0.012 Dynamic Range R80 R160 R80 R160 R80 R160 Min Reading(m³) 0.0001 Max Reading(m³) 99,999 Accuracy Class Class B, Class C, Class 2 ( R80, R100, R160 ) Standard ISO4064 / OIML R49 Measured Medium Water Maximum Permissible Error For The Lower Flow Rate Zone ±5% Maximum Permissible Error For The Upper Flow Rate Zone ±2% for water having a temperature <30°C Operating Temperature -10°C~55°C Accidental Temperature -20°C~55°C Max Loss(∆P) Δp63 Max Pressure(MAP) MAP16 Environmental Classification Class B Protection Class IP68 Material Brass 58-1 The Installation Senstivity U0/D0 Climatic and Mechanical M1 Communication Optical Port, M-BUS, RS-485, Pulse output, LoRa RF, LoRaWAN, NB-IoT, 4G (CAT 1) Installation Direction Horizontal Power Source Lithium batteries Module Battery Lifetime 10-15 years Historical Storage Data 1080 hours, 180 days, 24 months
±3% for water having a temperature > 30°C
Environmental Grades
INDICATING ERROR
At low zone is ±5% from minimum flow rate (qmin) to transitional flow rate (qt) exclusive boundary
At high zone is ±2% from transitional flow rate (qt) to overload flow rate (qs)
DIMENSIONS AND WEIGHT
Meter size Dia DN Length(L) Width(B) Height(H) Connecting Thread D Weight Kg (mm) mm 15 110 77 80 G 3/4B 0.57 20 130 77 80 G 1B 0.67 25 160 77 80 G1 1/4B 0.91
WORKING CONDITION
Water temperature：≤50℃ for cold water meter
Water temperature：≤90℃ for hot water meter
Working pressure：≤1.6Mpa
